Abstract
A hardware fuzzer, a unique testing tool, is designed to test hardware systems by introducing a variety of invalid, unexpected, or random inputs. It's an extension of software fuzzing, which targets software applications to find issues through unconventional input data. This type of fuzzer is particularly useful in developing embedded systems or crucial systems, including automotive, aerospace, and medical devices. However, it can test any hardware that enables system interfaces. Many systems enabled in their early stages can use this mechanism to see if the enablement has all the supported features enabled. There are many ways to test the system, and such methods can be used to find vulnerabilities and defects in software and hardware-based systems. In the current article, fuzzing Type-C devices involves applying unconventional inputs (test vectors) to test the device's behavior and identify vulnerabilities or defects. It would include sending invalid or unexpected input to the device and observing its behavior to identify potential vulnerabilities. Fuzzing a Type-C device can target various aspects such as the USB protocol, data transfer, power delivery negotiation, and other features.

Keywords:   Fuzzer, Hardware Fuzzing, Type-C Fuzzing, Device Fuzzer, Systems Fuzzer, Device Under Test for Fuzzer

1. Introduction
Hardware has become increasingly complex in terms of IP blocks in the last decade. Earlier, Moore’s law and Dennard scaling came to a standstill, and hardware engineers had to find novel ways to improve the performance gains of the hardware^4,5. USB Type-C ports are one main interface to communicate with the system. It supports charging, audio, video, data, and networking over it. Any attacker can control the host machine utilizing devices where the device behavior is altered to exploit. USB software devices and host software stacks are not designed to withstand such exploits as they are uncommon and not widely performed. They require physical access to the system, but having a vulnerability can open many doors for attacks⁶. Many types of USB Type-C devices communicate using standard PD messages. These messages are transmitted using I2C lines between the SOC and PD Controller and then to the device. These messages are communicated to the Host Controller devices on the SoC about the device type connected to the other end, and device descriptors are set up so that the system can enumerate and use the devices. Firmware is loaded into the PD controller to decode these messages and perform certain operations to and from the SoC. These modern attacks on the USB can come from the USB stack to USB specifications. Fuzzing has become the most popular tool for performing runtime testing on software environments and is quickly becoming popular in the hardware space. In many instances, fuzzing has revealed more bugs than automated or manual testing in software stacks^7,8. Some tools have detected over 50+ bugs in the USB Linux kernel subsystem⁹. All the current mechanisms to mitigate the threats from USB peripherals are focused on defending the host machines and checking for the USB host stack. However, many devices have multiple functionalities, such as devices and host functionalities combined in one device. It would make the stack more prone to failures and vulnerabilities because two software stacks need to be verified. Most USB Type-C bugs are found around the enumeration rather than in the USB core logic; hence, it has some stability in terms of the working functionality but not much in enumeration, partly because the CC lines and PD messages are doing that work.

2. Understanding of USB Stack
A typical USB Type-C stack has multiple layers. These layers represent the respective part of the OS from where it is operated. User space applications are covered using the HID device types over the Type-C connector. Multiple data types are getting transferred, such as audio, video, and files; hence, different applications use these spaces to make access and operation more accessible for the user.

The next layer in the stack is the kernel layer. Many software stacks are glued together in these layers to make the USB functional. Certain types of devices are classified into different classes, from where they are enumerated and operated further. Almost all USB devices have a core USB functionality where the core specifications of any USB devices are programmed and typically not altered or changed by any specific device type, as classes manage those. The kernel layer is responsible for communication with the hardware or the PHY layer, which uses the devices to be enumerated/detected by the host system.

3. USB Software Stack Fuzzing
Most USB fuzzers follow the software stack on the host side. Plenty of fuzzers are available to fuzz devices, such as USB devices. Still, there would be scenarios where USB devices are simulated to perform the fuzzing over the stack. In this case, the device would be simulated randomly by a mutation performed in the device class.

Using the mutation on the device class, the host must enumerate or restart the enumeration process once the device resets the connection. In repetition, this process would expose the software stack to issues in the enumeration area where most vulnerabilities are found. Performing such tests in the loop would make the host device more secure regarding the USB core software stack.

Type-C Fuzzing
Type-C is an extension of the USB stack where all the connectors follow the same USB spec in both cable orientations, making it a unique solution that accommodates different devices. It uses the CC line to connect the host and device with the power and alternate accessory modes as a part of the type-c device specification. Modifying the CC signal using a hardware simulator would change the device detection behavior using fuzzing. During the CC change, the device type messages would be mutated to simulate the virtual fuzzing device. Once the incorrect hardware behavior is recorded and stored, make sure that it will not be repeated in the next iteration of the steps to minimize the testing time. A hardware-based harness would trigger any user-desired actions based on the abnormal operation of the hardware detection. Using such a hardware fuzzer in a Type-C-based system would find PD firmware or other issues related to the power delivery negotiation sooner using the repetition in a continuous loop. Fortunately, Type-C PD communication uses I2C messages to negotiate or detect the devices and can be used to add the signal to the feedback loop.
